HOME > MAGNETIC CHUCK > HEAVY DUTY MULTICOIL ELECTRO MAGNETIC RECTANGULAR chuck

HEAVY DUTY MULTICOIL ELECTRO MAGNETIC RECTANGULAR chuck

Works holding device for surface grinding machines.

Each pole is having separate coil as such very strong & even magnetic flux is generated.

Mag-D-Mag with variable control unit allows to neutralize the residual magnetism precsely using a microoprocessor based control circuitry.

Polse individually magnetized for full liading power.

Variable ssupply to vary power which helps in alignment &removing of waepages ofthin jobs.

Chuck is tested for Slippeing force. Waterproof test emperature rise test. Electrical & Demagnetizing tests.

Also available in longitudinal Poles.

We also manufacture Special chuck to suit individual repuirements.

Good quality & standard electrical accessories.

Sr.	Code	Size in	Size mm	Pole	Number of	Net Weight
No	No	Inches	L X W X H	Pich mm	Pole	Kg
1	618	18 x 6 x 4	450 x 150 x 100	15	40	8 kg
2	820	20 x 8 x 4	500 x 200 x 100	15	40
3	824	24 x 8 x 4	600 x 200 x 100	15	40
4	1024	24 x 10 x 4	600 x 250 x 100	15	40
5	1224	24 x 12 x 4	600 x 300 x 100	15	40
6	1030	30 x 10 x 4	750 x 250 x 100	15	40
7	1230	30 x 12 x 4	750 x 300 x 100	15	40
8	1036	36 x 10 x 4	900 x 250 x 100	15	40
9	1230	30 x 12 x 4	900 x 300 x 100	15	40
10	1040	40 x 10 x 4.3/8	1000 x 250 x 110	15	40
11	1240	40 x 12 x 4.3/8	1000 x 300 x 110	15	40
12	1060	60 x 10 x 4.3/8	1500 x 250 x 110	15	40
13	1260	60 x 12 x 4.3/8	1500 x 300 x 110	15	40
14	1660	60 x 16 x 4.3/8	1500 x 400 x 110	15	40
15A		MaG D-MaG with variable controL uniT Upto 1000L 2Amp.
			Upto 1000L 3 Amp.
		MaG D-MaG with variable controL uniT Upto 1000L 2 Amp.
		& battery Back-up (20minutes)		Upto 1500L 3 Amp.
