HOME > MAGNETIC CHUCK > HEAVY DUTY FINE PITCH MULTI COIL ELECTRO MAGNETIC CHUCK

HEAVY DUTY FINE PITCH MULTI COIL ELECTRO MAGNETIC CHUCK

Works holding device for surface grinding machines.

Each pole is having separate coil as such very strong & even magnetic flux is generated.

Mag-D-Mag with variable control unit allows to neutralize the residual magnetism precsely using a microoprocessor based control circuitry.

Polse individually magnetized for full liading power.

Variable ssupply to vary power which helps in alignment &removing of waepages ofthin jobs.

Chuck is tested for Slippeing force. Waterproof test emperature rise test. Electrical & Demagnetizing tests.

Also available in longitudinal Poles.

We also manufacture Special chuck to suit individual repuirements.

Good quality & standard electrical accessories.

Sr.	Code	Size in	Size mm	Pole	Number of
No	No	Inches	L X W X H	Pich mm	Pole
1	618	18 x 6 x 4	450 x 150 x 100	4+1
2	820	20 x 8 x 4	500 x 200 x 100	4+1
3	824	24 x 8 x 4	600 x 200 x 100	4+1
4	1024	24 x 10 x 4	600 x 250 x 100	4+1
5	1224	24 x 12 x 4	600 x 300 x 100	4+1
6	1030	30 x 10 x 4	750 x 250 x 100	4+1
7	1230	30 x 12 x 4	750 x 300 x 100	4+1
8	1036	36 x 10 x 4	900 x 250 x 100	4+1
9	1230	30 x 12 x 4	900 x 300 x 100	4+1
10	1040	40 x 10 x 4.3/8	1000 x 250 x 110	4+1
11	1240	40 x 12 x 4.3/8	1000 x 300 x 110	4+1
12	1060	60 x 10 x 4.3/8	1500 x 250 x 110	4+1
13	1260	60 x 12 x 4.3/8	1500 x 300 x 110	4+1
14	1660	60 x 16 x 4.3/8	1500 x 400 x 110	4+1
15A		MAG D-MAG with variable controL uniT Upto 1000L 2Amp.
		MAG D-MAG with variable controL uniT Upto 1000L 3 Amp.
		MAG D-MAH with variable controL uniT Upto 1000L 2 Amp.
		& battery Back-up (20minutes)		Upto 1500L 3 Amp.
