HOME > fluke > Accessoriest > FLUKE - CODE i1010

Fluke i1010 AC/DC Current Clamp
Fluke current clamps extend the current ranges of Fluke tools. The Fluke i1010 AC/DC current clamp is highly reliable, measures 1A to 1000A and provides accurate current reading without breaking the circuit. This clamp measures both ac and dc current with a large jaw, battery-powered Hall-effect probe that gives access to difficult to reach areas. Compatible with most Fluke multimeters.

SR.	Fluke CODE
1	i1010

Specifications

Measurement type

Hall sensor

Nominal current range

600 A, AC

1000 A, DC

Continuous current range

1 A - 600 A, AC

1 A - 1000 A, DC

Maximum Non-Destructive Current

1000 A

Lowest measurable current

0.5 A

Basic Accuracy

2% + 0.5 A

(% reading + floorspec)

Useable frequency

DC - 10 kHz

Output level(s)

1 mV/A

Zero error adjustment

Yes

Safety Specifications

Safety

CAT III, 600 V

Maximum voltage

600 V

Mechanical & General Specifications

Warranty

1 year

Battery Life

9 V, 60 h

Maximum conductor diameter

30 mm

2 x 25 mm

Output cable length

1.6 m

Shrouded banana plugs

Yes
