HOME > Arete > Drill Vices > 1160

ARETE Code 1160
Heavy Duty Drill Vice
( S.G Ductile Iron Body )
( Size : 3",4", 6" ) Features :

Continuous Screw giving powerful grip on work.
No lifting of the sliding jaw.
Moving jaw is plain & fixed is provided with one vertical & one horizontal 90° V-grooves.
Its UNIQUE DESIGN and specifications like ample depth of jaws.
Slide Face is Machined, hence can be used upside down (Vertically).

Construction :

S.G. Ductile Iron Body

Specifications
Size in inches	Width of Jaws (in mm )	Opening of Jaws (in mm)	Depth of Jaws (in mm)	Height overall (in mm)	Length overall (in mm)	Width overall (in mm)	Weight (app. in Kgs.)
3	75	80	50	72	235	145	5
4	100	115	65	95	285	185	9
6	150	160	70	119	350	245	18

Heavy Duty Drill Vice 1160

Size in mm	STD. PKG.
75	4
100	3
150	2
